悬吊装配式竖井自动化掘进工法地层变形沉降实测及数值模拟分析

张振光, 周洁, 徐杰, 李泽垚, 刘成君

张振光, 周洁, 徐杰, 李泽垚, 刘成君. 悬吊装配式竖井自动化掘进工法地层变形沉降实测及数值模拟分析[J]. 应用基础与工程科学学报, 2024, 32(5): 1496-1510. DOI: 10.16058/j.issn.1005-0930.2024.05.022
引用本文: 张振光, 周洁, 徐杰, 李泽垚, 刘成君. 悬吊装配式竖井自动化掘进工法地层变形沉降实测及数值模拟分析[J]. 应用基础与工程科学学报, 2024, 32(5): 1496-1510. DOI: 10.16058/j.issn.1005-0930.2024.05.022
ZHANG Zhenguang, ZHOU Jie, XU Jie, LI Zeyao, LIU Chengjun. Ground Settlement Measurement and Numerical Simulation Analysis of Vertical Shaft Machine[J]. Journal of Basic Science and Engineering, 2024, 32(5): 1496-1510. DOI: 10.16058/j.issn.1005-0930.2024.05.022
Citation: ZHANG Zhenguang, ZHOU Jie, XU Jie, LI Zeyao, LIU Chengjun. Ground Settlement Measurement and Numerical Simulation Analysis of Vertical Shaft Machine[J]. Journal of Basic Science and Engineering, 2024, 32(5): 1496-1510. DOI: 10.16058/j.issn.1005-0930.2024.05.022

悬吊装配式竖井自动化掘进工法地层变形沉降实测及数值模拟分析

基金项目:

上海市科学技术委员会上海工程技术研究中心与专业技术服务平台项目(20DZ2251900);上海市青年科技英才扬帆计划项目(20YF1416200)

详细信息
    作者简介:

    张振光(1981-)男,高级工程师,一级建造师.E-mail:lzy004@tongji.edu.cn

    通讯作者:

    周洁(1986-),女,副教授,博士生导师.E-mail:15050@tongji.edu.cn

  • 中图分类号: TU91

Ground Settlement Measurement and Numerical Simulation Analysis of Vertical Shaft Machine

  • 摘要: 垂直竖井沉降掘进工法(VSM)是一种通过机械臂在水下对地层进行摆幅开挖并同时进行预制管片拼装作业的下沉式竖井掘进施工新方法.以上海竹园白龙港污水连通管工程为背景,综合对比分析理论计算、现场实测和数值模拟结果,从而对VSM施工技术在上海软土地区首个工程案例进行系统性技术分析.现场实测表明,VSM掘进开挖引起的最大地表沉降为15.2mm,最大水平位移为3.74mm,竖井开挖对地表沉降的影响范围约为30m;相比于传统的地下连续墙下的基坑开挖施工,该工法对上海软土地层的适用性较强.应用有限元分析方法,对VSM竖井施工过程中地层沉降变形、土压力变化、竖井失稳与突涌风险进行了数值模拟分析,并讨论了数值模拟结果与基坑理论计算、现场实测结果的差异性.研究结果表明:采用流固耦合、弹塑性模型、莫尔-库伦准则、比奥固结模型进行的数值计算可有效对VSM竖井施工进行仿真模拟;VSM竖井整体开挖的过程中,井底稳定性安全系数皆大于1.8,整体发生土体失稳、井底突涌的风险性非常小.最后对VSM施工技术对工程环境的影响进行分析总结,并为未来其他实际工程的变形控制提出应对方案与合理化建议.
    Abstract: The vertical shaft machine (VSM) construction method is a new submerged shaft excavation construction method in which the manipulator is used to excavate saturation stratum and assemble the prefabricated segments at the same time.This paper takes Shanghai Zhuyuan Bailonggang Sewage Connecting Pipe Project as engineering background,comprehensively compares and analyzes the theoretical calculation,field measurement results and numerical simulation results,so as to systematically analyze the first engineering case of VSM in Shanghai soft clay area.The field measurement shows that the maximum ground surface settlement is 15.2mm,the maximum horizontal displacement is 3.74mm,and the influence range on surface settlement is about 30m.Compared with the excavation construction under the traditional diaphragm wall,VSM has strong applicability to soft clay layer in Shanghai.Using the finite element analysis method,the numerical simulation of VSM construction method for the settlement and deformation,earth pressure,shaft instability and inrush risk are carried out.And the difference along with numerical simulation results,the theoretical calculation and field measurement results of VSM is discussed.Results show that the numerical calculation using fluid-solid coupling,elastoplastic model,Mohr-Coulomb criterion and Biot consolidation model can effectively simulate the construction of VSM.And the safety factor of shaft stability is greater than 1.8,so that the risk of soil instability and bottom hole inrush is very small.Finally,the countermeasures and suggestions for deformation control in the future are put forward.
  • [1] 祁小龙.地铁竖井开挖对邻近建筑物影响的监测系统研究[J].建筑施工, 2019, 41(9):1757-1760

    Qi Xiaolong.Study on monitoring system of influence of metro shaft excavation on adjacent buildings[J].Building Construction, 2019, 41(9):1757-1760

    [2]

    Combrinck R, Steyl L, Boshoff W P.Influence of concrete depth and surface finishing on the cracking of plastic concrete[J].Construction & Building Materials, 2018, 175(JUN.30):621-628

    [3] 行业信息[J].地下工程与隧道, 2012, (2):66-67

    Industry information[J].Underground Engineering and Tunnel, 2012, (2):66-67

    [4] 国内首座VSM沉井式地下停车库工程启动[J].江西建材, 2021, (1):74

    The first VSM caisson underground parking garage project in China was started[J].Jiangxi Building Materials, 2021, (1):74

    [5]

    Peter S.Vertical shaft machines:State of the art and vision[J].Acta Montanistica Slovaca, 2007, 12(1):208

    [6]

    Schmäh P, Berblinger S.VSM shaft sinking technology:Mechanized shaft sinking with the VSM in different projects for subway ventilation shafts[C].Proceedings of the World Tunnel Congress, 2014

    [7] 下沉式竖井摒进设备[J].地质装备, 2017, 18(1):47-48

    Equipment for sinking shafts[J].Geological Equipment, 2017, 18(1):47-48

    [8] 张振光, 徐 杰, 汪 盛, 等.富水地层超深装配式竖井水下机械法掘进施工技术——以南京某沉井式停车设施建设项目为例[J].隧道建设(中英文), 2022, 42(3):492-500

    Zhang Zhenguang, Xu Jie, Wang Sheng, et al.Underwater mechanical tunneling technology of an ultra-deep assembled shaft in water-rich stratum:A case study of sinking shaft underground parking garage in Nanjing, China[J].Tunnel construction (Chinese and English ), 2022, 42(3):492-500

    [9] 黄铭亮, 张振光, 徐 杰, 等.基于VSM沉井施工过程的井壁受力实测研究——以南京沉井式地下智能停车库工程为例[J].隧道建设(中英文), 2022, 42(6):1033-1043

    Huang Mingliang, Zhang Zhenguang, Xu Jie, et al.Measuring of shaft wall stress in caisson construction process based on vertical shaft sinking machine:a case study of caisson-type underground intelligent parking garage project in Nanjing, China[J].Tunnel Construction, 2022, 42(6):1033-1043

    [10] 姜 弘, 包鹤立, 林咏梅.装配式竖井设计与施工技术应用研究——以南京某沉井式地下车库项目为例[J].隧道建设(中英文), 2022, 42(3):463-470

    Jiang Hong, Bao Heli, Lin Yongmei.Research and application of design and construction technology of assembled shaft:A case study of a sinking shaft underground parking garage in Nanjing, China[J].Tunnel construction (Chinese and English), 2022, 42(3):463-470

    [11] 曹程明, 龙 照, 时轶磊, 等.小尺寸深竖井侧壁内力与变形分布规律计算分析[J].地下空间与工程学报, 2022, 18(增1):51-56+73

    Cao Chengming, Long Zhao, Shi Yilei, et al.Calculation and analysis of internal force and deformation distribution law of side wall of small size deep shaft[J].Underground Space and Engineering Journal, 2022, 18(S1):51-56+73

    [12] 郑榕明, 胡亚元.竖井衬砌主动土压力在一般环向压应力系数下的简化滑移线解(英文)[J].岩土工程学报, 2005, (1):110-115

    Zheng Rongming, Hu Yayuan.Active earth pressure on circular shaft lining obtained by simplified slip line solution with general tangential stress coefficient[J].Journal of Geotechnical Engineering, 2005, (1):110-115

    [13]

    Prater E.An examination of some theories of earth pressure on shaft lining[J].Canadian Geotechnical Journal, 1977, 14(1):91-106

    [14]

    Bowles J E.Foundation analysis and design[J].Berkshire, England:McGraw-Hill Publishing Co., 1988

    [15]

    Hsieh P, Ou C.Shape of ground surface settlement profiles caused by excavation[J].Canadian Geotechnical Journal, 1998, 35(6):1004-1017

    [16] 魏福贵, 朱牧原, 李 鳌, 等.考虑松动圈的深大竖井稳定性及受荷特性分析[J].地下空间与工程学报, 2021, 17(增2):662-669+702

    Wei Fugui, Zhu Muyuan, Li Ao, et al.Analysis of stability and load characteristics of deep shaft considering the loose zone[J].Underground Space and Engineering Journal, 2021, 17(S2):662-669+702

    [17]

    Clough G W, Duncan J M.Finite element analysis of retaining wall behavior[J].ASCE, 2001, 12:20-25

    [18]

    Hu Z, Kang Z, Hu F.Application researches on lasson steel sheet pile based on foundation pit support close to railway bridge[J].Applied Mechanics and Materials, 2011, 97-98:414-417

    [19]

    Brooks J, Megat J.Effect of metakaolin of creep and shrinkage of concrete[J].Cement and Concrete Composites, 2001, 23:495-502

    [20]

    Combrinck R, Steyl L, Boshoff W P.Influence of concrete depth and surface finishing on the cracking of plastic concrete[J].Construction & Building Materials, 2018, 175(JUN.30):621-628

    [21]

    Li J, Yao Y.A study on creep and drying shrinkage of high performance concrete[J].Cement and Concrete Research, 2001, 31(8):1203-1206

    [22] 周振梁, 谭忠盛, 李宗林, 等.一种基于数据挖掘的掘进速度预测模型[J].应用基础与工程科学学报, 2021, 29(5):1201-1219

    Zhou Zhenliang, Tan Zhongsheng, Li Zonglin, et al.A data mining based prediction model for penetration rate[J].Journal of Applied Basic and Engineering Sciences, 2021, 29(5):1201-1219

    [23] 陈永兴, 陈金浦, 祝维霖, 等.深厚软土地层圆形沉井受力性能实测[J].建筑技术开发, 2021, 48(14):84-86

    Chen Yongxing, Chen Jinpu, Zhu Weilin, et al.Field measurement of mechanical performance of a circular caisson in deep soft-soil[J].Building Technology Development, 2021, 48(14):84-86
