城市化地区Landsat水体指数适用性分析

杨振华; 赵铜铁钢; 林鸿章; 陈晓宏

doi:10.16058/j.issn.1005-0930.2023.03.002

城市化地区Landsat水体指数适用性分析

杨振华^1,2,3,
赵铜铁钢^1,2,3, ,,
林鸿章^1,2,
陈晓宏^1,2

1. 南方海洋科学与工程广东省实验室(珠海), 广东珠海 519000;
2. 中山大学土木工程学院, 广东广州 510275;
3. 广东省华南地区水安全调控工程技术研究中心, 广东广州 510275

基金项目:

国家自然科学基金项目(51979295,51861125203,U1911204)

国家重点研发计划项目(2017YFC0405900)

广东省科技厅项目(2019ZT08G090)

详细信息

作者简介:
杨振华(1991-),男,博士研究生.E-mail:yangzhh63@mail2.sysu.edu.cn

通讯作者:
赵铜铁钢(1986-),男,教授.E-mail:zhaottg@mail.sysu.edu.cn

中图分类号: P237
计量
- 文章访问数: 232
- HTML全文浏览量: 27
- PDF下载量: 63
出版历程
- 收稿日期: 2022-01-13
- 修回日期: 2022-08-04
- 网络出版日期: 2023-05-03

Interpretation and Applicability Analysis of Landsat Water Index in Urbanized Areas

1. Southern Marine Science and Engineering Guangdong Laboratory(Zhuhai), Zhuhai 519000, China;
2. School of Civil Engineering, SunYat-sen University, Guangzhou 510275, China;
3. Guangdong Engineering Technology Research Center of Water Security Regulation and Control for Southern China, Guangzhou 510275, China

摘要

摘要: 遥感水体指数是地表生态环境分析的重要基础,在大规模水体提取与水文监测中起关键作用.多种水体指数研究集中于大尺度、短历时、非城市化为主的区域,而对于城市化地区的水体指数适用性问题却一直困扰着城市水体的提取.针对常用水体指数(TCW、NDWI、MNDWI)和改进的新型水体指数(WI2015、AWEInsh、ANDWI、MBWI、WI2020),搜集深圳市1986~2020年逐月Landsat影像,以建筑阴影、亮建筑、暗建筑、滩涂噪声和山体阴影5种案例区为例,分析不同水体指数在城市地表覆被噪声区的解译能力.结果表明:(1)水体指数的生产者精度与用户精度呈负相关(Otsu阈值),TCW、NDWI、ANDWI、AWEInsh可有效过滤建筑类噪声和山体阴影,但无法识别细小河流水体,MNDWI、WI2015、MBWI、WI2020则相反;(2)光谱变换型和差值型水体指数考虑多波段的绝对值,可分离度较低,适用于高质量影像制图,比值型和逻辑运算型水体指数计算多波段的相对值,更适用于长序列监测;(3)多案例、多时相的案例区抽样验证方法有效突显出水体指数的解译能力和阈值适用性,城市地区NDWI适用性最强,非城市地区WI2020提取精度最高.上述研究为城市水文监测过程的水体指数选取、精度验证提供了一定的理论参考和实践依据.
- 水体指数 /
- 适用性分析 /
- Landsat影像 /
- 城市化 /
- 水文监测 /
- 可分离度 /
- 阈值
Abstract: Remote sensing water indices are important basis for surface eco-environment analysis,and are critical to large-scale waterbody interpretation and hydrological monitoring.A variety of water indices focus on large-scale,short-term,non-urbanized regions,while the extraction of urban water bodies has been plagued by the applicability of these indices.The study collected Landsat images from 1986 to 2020 in Shenzhen city,and adopted three commonly used water indices(TCW,NDWI,MNDWI) and five improved water indices(WI2015,AWEInsh,ANDWI,MBWI,WI2020).The interpretation ability of these water indices in the urban noise area were analyzed by taking five regions of building shadow,high albedo building,low albedo building,tidal-flat and mountain shadow as examples.The results show that:(1)Producer accuracy of water indices are negatively correlated with user accuracy(Otsu threshold),and TCW,NDWI,ANDWI,AWEInsh can effectively filter architectural noise and mountain shadow,but unrecognize small river water bodies,MNDWI,WI2015,MBWI,WI2020 are the opposite;(2)The spectral transformation type and difference type water indices consider the absolute value of multiple bands with low separability,and they are suitable for high-quality image mapping.The ratio type and logical operation type water indices calculate the relative value of multiple bands,and suitable for long-term monitoring;(3)The method of multi-temporal sampling verification in typical cases highlights the interpretation ability and threshold applicability of water indices,and the NDWI is most applicable in urbanized areas,while the WI2020 achieves the highest interpretation accuracy in non-urbanized areas.The above research provides a certain theoretical reference and practical basis for the selection of water index and accuracy verification for urban hydrological monitoring.
- water index /
- applicability analysis /
- Landsat image /
- urbanization /
- hydrological monitoring /
- separability /
- threshold
